JBM EDM Wire Group Taiwan--JIA BAO Metal Co., Ltd.

    Testing Equipment

    E.D.M. Wire
    Zin coated wire
    Brass Wire
    Other Wire


WIRE TYPE	MODEL NO	DIAMETER		DIAMETER TOLERANLE(mm)	BREAKING LOAD (kg)	TENSILE STRENGTH (/Nmm²)	ELONGATION (%)
		inch	mm
HARD	BZ-10H BZ-15H BZ-20H BZ-25H BZ-30H BZ-33H	0.004 0.006 0.008 0.010 0.012 0.013	0.10 0.15 0.20 0.25 0.30 0.33	±0.001	0.78 1.73 3.14 4.92 7.07 8.55	980≦	0.4≦
SOFT	BZ-20S BZ-25S BZ-30S	0.008 0.010 0.012	0.20 0.25 0.30	±0.001	1.41 2.21 3.18	441≦	15≦

★ 65/35 brass equivalent to Alloy No.JIS-H3260 C2700
