NATURE OF WORK

WIRE TYPE

SOFT MEDIUM HARD

STRAIGHT
CUTTNG

1Pass cutting

 X

2Pass cutting
(rough+finish)

 X X

3Pass cutting
(rough+finish+re-finish)

 X X

PELIEF
CUTTNG

1Pass cutting
Relief under 10°

X

1Pass cutting
Relief under 10°~20°

X

1Pass cutting
Relief over 20°

X

Performance:ecellent        good            not recommended



COIL TYPE COIL
SHAPE		 WEIGHT OF WIRE ON COIL(kg) DIAMETER OF WIRE(mm) D
(mm)		 d
(mm)		 L(mm) h(mm) LENGTH OF WIRE ON COIL(mm) NUMBER
 OF COILS
/BOX

P-3R

3 0.10
0.15
0.20
0.25		 130 80 110 20 39360
18750
10988
6932		 6

P-5R

5 0.20
0.25
0.30
0.33		 160 90 114 20 18314
11553
8001
6750		 4

P-15

20 0.20
0.25
0.30
0.33		 250 110 140 30 73256
46212
32004
27000		 1

k125

3.5 0.10
0.15
0.20
0.25		 125 80 125 20 12820
8087
5600
4725		 4

k160

7 0.20
0.25
0.30
0.33		 160 100 160 22 25640
16174
11200
9450		 2

k200

16

0.20
0.25
0.30
0.33

 200 125 200

22

58605
36970
25603
21600

1



                             Other coil types媲weight and diameter wire may be proposed on request.

                             This represents a DIN (German)standard coil嫂primarily designed for
                                        AGIE and CHARMILLES machines.
